"ALLIED 48-port 10/100/1000T 4-port 100/1000X SFP Gigabit Ethernet Managed switch 1 Fixed AC power s
150-AT-GS980M/52-50
Main info
Warning: Last items in stock!
| Switch-Typ | Managed |
| Eigenschaft | Wandmontage |
| MIB Unterstützung | SNMP MIB |
| Anzahl der basisschaltenden RJ-45 Ethernet Ports | 48 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
| Anzahl installierten SFP Module | 4 |
| Optischer Kabelverbinder | SFP |
| Netzstandard | IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Kupfer Ethernet Verkabelungstechnologie | 10BASE-T, 100BASE-T, 1000BASE-T |
| Virtuelle LAN-Funktionen | Port-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN |
| Anzahl der VLANs | 4094 |
| Ethernet-Kabel Verkablungstechnologie | 100BASE-X, 1000BASE-X |
| Schalttyp optisches Modul | 100 Gigabit Ethernet |
| Routing-/Switching-Kapazität | 104 Gbit/s |
| Transferrate | 77,4 Mpps |
| MAC-Adressentabelle | 16000 Eintragungen |
| Wartezeit (10-100 Mbps) | 5,5 µs |
| Wartezeit (1 Gbps) | 2,6 µs |
| Jumbo-Frames | 10000 |
| Datenpaket-Pufferspeicher | 1,5 MB |
| DHCP-Funktionen | DHCP client, DHCP snooping |
| Unterstützte Sicherheitsalgorithmen | 3DES, AES, MD5, PEAP, RSA, SHA-1, SHA-2, SSH, SSH-2, SSL/TLS, TTLS |
| Authentifizierung | MAC-basierte Authentifizierung, Port-basierte Authentifizierung, Webbasierte Authentifizierung |
| Autentifizierungstyp | AAA, IEEE 802.1x, Network Access Control (NAC), RADIUS |
| Management-Protokolle | SNMP |
| Router Protokoll | RIP, RIP-2 |
| Produktfarbe | Grau |
| Elektromagnetische Verträglichkeit | EN55024 |
| Speichertyp | DDR-SDRAM |
| Speicherkapazität | 256 MB |
| Flash-Speicher | 64 MB |
| Geräuschpegel | 39 dB |
| AC Eingangsspannung | 100 - 240 V |
| AC Eingangsfrequenz | 50 - 60 Hz |
| Eingangsstrom | 1.0 A |
| Stromverbrauch (Standardbetrieb) | 47 W |
| Betriebstemperatur | 0 - 50 °C |
| Temperaturbereich bei Lagerung | -25 - 70 °C |
| Relative Luftfeuchtigkeit in Betrieb | 5 - 90% |
| Luftfeuchtigkeit bei Lagerung | 5 - 95% |
| Höhe bei Betrieb | 0 - 3000 m |
| Höhe bei Lagerung | 0 - 4000 m |
| Wärmeableitung | 160 BTU/h |
| Gewicht | 4,5 kg |
| Verpackungsbreite | 575 mm |
| Verpackungstiefe | 445 mm |
| Verpackungshöhe | 150 mm |
| Paketgewicht | 6,4 kg |
| Zertifizierung | UL60950-1, CAN/CSA-C22.2 No.60950-1-03, EN60950-1, EN60825-1, AS/NZS60950.1UL, cUL, UL-EURoHS |
| Warentarifnummer (HS) | 8517,62,0050 |
